LAS7006 si Meeting Stile Seal
Face-fixed
A high performance seal designed for use on plain or rebated meeting stiles. With proven medium temperature smoke performance, it also makes a positive contribution to light, sound, and draught containment. The leg can be cut out to make way for locks and latches.
Finish
![](/imager/files/276073/LAS7006-in-situ-no-fire-door-signs_5472332afa344033d2bf9e7b6b9d883e.png)
![](/imager/files/276033/LAS7006-isometric-web_5472332afa344033d2bf9e7b6b9d883e.png)
![](/imager/files/276944/LAS7006-cross-section-web_2023-10-20-154327_qchi_5472332afa344033d2bf9e7b6b9d883e.png)
![](/imager/files/276073/LAS7006-in-situ-no-fire-door-signs_905a32f077cde75e59ae4f0bd185c8e7.png)
![](/imager/files/276033/LAS7006-isometric-web_905a32f077cde75e59ae4f0bd185c8e7.png)
![](/imager/files/276944/LAS7006-cross-section-web_2023-10-20-154327_qchi_905a32f077cde75e59ae4f0bd185c8e7.png)
System specification
Property | |
---|---|
TEST EVIDENCE | Smoke: BS EN 1634-3:2004 at ambient and medium temperature; effective smoke seal up to 200°C |
Performance | Protects against smoke, sound, draught, dust, light and weather |
LOCATION | Meeting stiles of single swing doors. Double doors – where only one door leaf is in use |
SEAL MATERIAL | Aluminium carrier with flexible silicone blade |
FINISHES | Silver anodised aluminium with grey silicone rubber gasket as standard. Other finishes available to special order (non-standard - charges and lead times apply) |
STANDARD LENGTHS | 2.1m |
Fixing | Secure with heavy duty self-adhesive tape. Screw into place (fixings supplied) |
