Batwing®-On-A-Stick Perimeter Seal

LAS1206K + LAS1212K

  • LAS1206K
  • LAS1212K

A range of popular, medium duty, acoustic + smoke perimeter seals; which minimise the opening + closing resistance of the door leaf due to their unique, curved fins. Flexible elastomeric fin material springs back to original shape to provide ongoing performance + durability in service. They can be fitted with minimal disruption to the door assembly.

Colour

System specification

PropertyLAS1206KLAS1212K
LOCATIONHead + jambs of single + double leaf doorsHead + jambs of single + double leaf doors
MIN/MAX GAP SIZES3mm/4mm3mm/4mm
SEAL MATERIALCo-extruded rigid back PVC with flexible finsCo-extruded rigid back PVC with flexible fins
STANDARD LENGTHS1m + 2.1m. Single doorset pack consisting of 1 x 1m + 2 x 2.1m. Other lengths to special order1m + 2.1m. Single doorset pack consisting of 1 x 1m + 2 x 2.1m. Other lengths to special order
TEST EVIDENCEAcoustic: BS EN ISO 10140-2: 2010 (up to Rw 41dB). Durability: minimum of 100,000 cyclesAcoustic: BS EN ISO 10140-2: 2010 (up to Rw 41dB). Durability: minimum of 100,000 cycles
PERFORMANCEMeets smoke requirement: BS 9999: 2017Meets smoke requirement: BS 9999: 2017
ACCREDITATIONS
CertifireCF5179
ULR27972R27972
BBA92/284192/2841
